BH300-01 and BH300-02 Fuse Holders

ADLER’s BH300-01 and BH300-02 safety contact fuse holders are designed for all standard 10 x 85 mm photovoltaic fuses, such as the ADLER ELECTRIC A75/A85/A65 series, and other cylindrical fuses up to Φ10 x 85 mm/Φ14 x 85 mm.

With rated currents up to 50 A at 1500 VDC, they effectively protect 1500 VDC circuits and equipment in photovoltaic applications.

The BH300-01 and BH300-02 safety fuse holders are designed for Φ10 x 85 mm/Φ14 x 85 mm cylindrical fuse links, specifically for use with photovoltaic equipment. The BH300-02 safety fuse holder features a short circuit indicator light that illuminates when the circuit is interrupted.

 Rated Voltage: 1500 Vdc
 Rated Current: up to 50 A
 Short Circuit Current Rating (SCCR): DC 50 kA
 Standards: UL 4248-19 and EN 60947-3
(500 kA at 1500 Vdc)
 Max. Dissipation: 8.5 W
 Material Flammability: UL 94-V0
 Mounting: DIN Rail mounting
 Max. Torque: 3.0 N.m
 Wire Range: 4-18AWG
 Temperature Tolerance: -40 °C to +130 °C
